50A 600V ADSB50 dual pole high current power solar battery connector plug

  • Brand: ADSTech
  • Quality: Meet RoHS/ CE Standard
  • Size: 48.1*36.4*16mm
  • Rated Current: 50A@600V
  • Product description: 50A 600V ADSB50 dual pole high current power solar battery connector plug are designed and manufactured by ADS Tech. company in China
  • INQUIRY

ADS Aitm series High Current power connector is a brand from China, “A” and “B” series identify the single pole and dual pole products, the connectors provide cost-effective quality and reliability, design flexibility and safety, equal the famous brands APP, REMA, TYCO,AMP,SMH and KSJ.

     The power connectors are widely application in Military, Avionics, Boat, Yacht, Bus, Vehicles, Golf Cart , Forklift, e-sweeper, all kind of automotive, posts and telecommunications, communications, electricity, solar system, coal, aerospace, defense, surveillance systems, railway signals, medical equipment, instruments and meters, EV Charging system, AGV, IoT, Robot and other automation fields.

1. Features

Genderless Housings

Quick and easy assembly

Low Resistance Connection

Silver or tin plated copper contacts inside housings provide tightly connection

Support Hot Plug

Contacts design a sacrificial tip that allows high current circuit interrupt

Color identified housings

Prevent accidental mating at different voltage levels

Self-Securing Design

Stainless steel springs create a robust force between the contacts to fix the connector in the mated position

Auxiliary or Ground Positions

Use for signal transmission or promote safety of contacts


2. Specifications

Connector Model

ADSB50

Rated Current

A

50

Rated Voltage

V

600

Contact Barrel Wire Size

AWG/ mm²

6/10/12AWG (13.3/5.3/3.3mm²)

Average Contact Resistance

0.05

Insulation Withstanding Test Voltage

Vdc

2200

Insulation Resistance

MΩ

>500

No load Contact/Disconnect Cycles

times

>10,000

Under Load (Hot Plug 250 cycles@120V

A

50

Avg. Connect/Disconnect Force

N

53

Operating Temperature Range

C

-20°to 125°

Size

mm

48.1*36.4*16

Flammability Rating of Housing Material

UL94 V-0

Contact material

Silver plated copper

3. Temperature Rise Charts
